Australia Hotel Ballroom Retractable Mobile Acoustic Partition Movable Walls System
Mobile acoustic partitions advantage
1.Hanging on ceiling. The floor without a track, just put the rail mounted on the ceiling
2.Excellent Quality. Each pieces of mobile acoustic partition can turn around 360 degree.
3.Stable and secure. After mobile acoustic partition is stable and reliable, and is not easy to swing
4.Energy efficient. The large space divided into a small space, in order to reduce air conditioning power consumption;
5.Heatproof & fireproof: Good heat insulation performance, Adopt effective fire prevention materials
6.Elegant appearance. Surface any adornment, can unite with indoor adornment effect
7.Easy to collect. Can be hidden in the special coffer, does not affect the overall appearance
8.Various applications. Hotels, exhibition halls, restaurants, multi-functional rooms etc.
Technical Information
| Model | 65 mobile acoustic partitions | 85 mobile acoustic partitions | 100 mobile acoustic partitions | Ultra-high system mobile acoustic partitions |
| Panel Thickness | 65 MM | 85 MM | 100mm | 100mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm | 680mm-1230mm | 680mm-1230mm |
| Panel Height | 2000mm-4500mm | 3000mm-6500mm | 5000mm-8500mm | 7000mm-17000mm |
| Frame | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium |
| Acoustic alreduction coefficient(db) | 32db | 45db | 60db | 60db |
| Hermetic flex distance(mm) | 45mm | 45mm | 45mm | 60mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 | 40,45,48,55 | 60,60,60,60 |
| Faceplate Material | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
| Panel Surface Finish | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Mobile acoustic partitions details
Mobile acoustic partition wall system for modern living spaces Rooms of different types and usage can be divided, reduced in size, enlarged, have their proportions modified and thus be adapted on demand to the different number of people using them. From the small conference room to the large exhibition hall. This flexibility generates a special atmosphere, characterized by creative aesthetics and enhanced by a wide range of surface materials and finishes.
Mobile acoustic partition is also called sliding partition or movable sound insulation wall, which is widely used to divide big rooms into small rooms. Each piece of partition can turn around 360 degree which makes it flexible. Different core materials decide its sound insulation performance and various finishes make it adapt to many projects.
BUNGE mobile acoustic partitions system thickness is 85 mm, it can be double or single piece, and can be designed U shape or L shape door. every panel can board 225 kgs weight. The top and bottom flex range is 22.5mm.
