Hotel Acoustic Temporary Sound Proof Partitions Sliding Folding System
Temporary sound proof partitions details:
Brand Name:BUNGE
Year of Establishment:2011
Model Number:65 mm temporary sound proof partitions.
MOQ:No MOQ, small quantity welcomed.
Delivery Time:10-30 days.
Supply Ability:5000 square meters per month.
Packing Details:Carton package,outside with wooden boxes.
Payment Terms:T/T is most common for us,others are also ok.
The temporary sound proof partition walls shall be top-supported, manually operated panels stacked in an area nominated in the plans. When closed, the temporary sound proof partitions shall provide a complete sound retardant barrier. No floor track shall be used. The tracks are made from extruded anodized aluminum. The temporary sound proof partitions track housing shall utilize grooves and interlocking steel pins for better alignment of adjacent track section, and shall be reinforced overhead by drop rod brackets.
Technical Information
| Model | 65 temporary sound proof partitions | 85 temporary sound proof partitions | 100 temporary sound proof partitions | Ultrahigh temporary sound proof partitions |
| Panel Thickness | 65 MM | 85 MM | 100mm | 100mm |
| Panel Width | 680mm-1210mm | 680mm-1230mm | 680mm-1230mm | 680mm-1230mm |
| Panel Height | 2000mm-4500mm | 3000mm-6500mm | 5000mm-8500mm | 7000mm-17000mm |
| Frame | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium | 6063 T6 Aluminium |
| Acoustic alreduction coefficient(db) | 32db | 45db | 60db | 60db |
| Hermetic flex distance(mm) | 45mm | 45mm | 45mm | 60mm |
| Weight(kg/m) | 17,19,20,24 | 24,25,28,38 | 40,45,48,55 | 60,60,60,60 |
| Faceplate Material | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass | Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass |
| Panel Surface Finish | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment | Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment |
Temporary sound proof partitions features
1. We are the temporary sound proof partitions supplier from China,we are the 100％ real manufacturer,we have our own factory and showroom.Our factory located in Guangzhou,China.Very welcome to visit us
2. About the temporary sound proof partitions,they are sound proofing,sliding and operable.When you use them,they can be divided a big space into many small rooms,and when you do not use them,they can be parked at one site.
3. The temporary sound proof partitions are a hanging system,just have the ceiling rails,but has no rails on the floor.So the partition walls will not damage your floor or carpet.
Please do not worry,they are easy to install.Before we deliver the partitions,we will mark them one by one,and we will send you the installation drawing.
4. As for the surfaces,there are 4 kinds of surfaces for you to choose:
Plywood(you can decorate the surfaces at your site,such as painting,wallpapersand so on).
Melamine(the most welcomed surface,there are many colors to choose and very easy to clean).
Fabric and leather surfaces(can be a soft cover,will be more sound proofing).
