Hotel Acoustic Sliding Decorative Banquet Hall Sound Proof Folding Partition Wall
In creating spaces that respond quickly to the needs of any size or work, it is essential to minimize distractions from neighboring noises to create an effective work atmosphere. The operable wall is a new movable wall that meets these needs. Our superior design provides a gigantic panel 13 meters in height. A smooth and quiet run The special nut and rubber on the trolley bearing of the panel prevents one-wheel-run, enabling the wall to glide smoothly and quietly. Using our proprietary suspension system , the wall slides safely and requires only minimal power to push. Exceeding design standards, the wall's high durability has been verified by a public institution . Superior Soundproofing with a Beautiful Finish We selected materials with excellent soundproofing for the panel surface , as well as the filling and sealing materials . The excellent sound resistance of the top and bottom panel segments mutes surrounding sounds to create a distinctly separate space. The panel surface is available in your choice of painted or cloth finish for a wall surface that meets your needs.
The movable partition offers superior soundproofing employing a high-precision aluminum vibration suppression plate for the panel surface. The four-layer panel with its newly developed soundproofing seal mechanism exerts a 50db soundproofing capacity equivalent to the sound suppression of 150mm-thick concrete. The main structure, built of metal alloy, provides a lighter panel with excellent operability. The high-precision aluminum panel excels in precision steering and smoothness and is designed with a beautiful surface finish.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door |
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) |
Components of Sliding Partition Walls
Tracks: Made of good quality anodized aluminium 6063-T5 materials,hanging the movable partition walls with wheels.
Wheels/Rollers: It is the carrier for the movable partition walls ,let panels move more flexibly.Pulley bearing is more than 1600 KGS.
Connectors: Made of anodized aluminium 6063-T5 aluminum tracks,“L”, “T”, “＋”types are available.
Rubber/vinyl seal: Made of Nitrile Butadiene Rubber(NBR+PVC),durable and perfect for sound insulation,wear-resistant.
Rock Wool: Density of 60kg/m3,help us reduce the noise and heat.
Handle: Operate the retractable being up and down.
Retractable mechanism: Control the movement of the top and bottom seal to form a excellent sound insulation performance.
Magnetic Strip: Ferrite plastic magnetic material will be used in between aluminum profiles to enhance acoustic performance of the movable partition walls.
MDF board: 9 mm thickness,density of 760kg/m3,absorbent thickness expansion rate is less than 15%.Formaldehyde emission is 34mg/100g.
