Home House Wooden Sliding Waterproof Wall Partition Door For Classroom
The details of folding wall partitions
Our operable or movable folding wall partitions are the quality option for Maximilian the use of space within offices, educational establishments and hotels.
Using a system of individual interlocking panels that once in place give the same quality, aesthetics and sound reduction as a permanent partition wall they are the ideal solution for use in larger areas such as conference and meeting rooms where the space is used for a diverse range of activities.
Each folding wall partitions panel within a movable partition wall system can be stored away completely when not in use to maximize the available floor space. Additionally there are numerous ways of stacking or configuring the individual acoustic wall panels to give full versatility on how the area is used.
Structure
The Steel panels are manufactured of acoustical substrate pressure laminated to both sides of steel framing members. The finish material can be wrapped around the vertical edges of the panel to create a seamless appearance between adjacent panels (standard) or the vertical edge can be completely encapsulated and protected by a decorative aluminum trim (optional). For added durability, an optional steel skin can be laminated on top of the substrate material.
The folding partition wall panels are available with standard acoustical substrate or optional steel skins for added durability.
Standard brimless vertical astral provide a positive interlock with adjacent panels that prevent sound leaks while producing a minimal seamless appearance at the panel face.
With a standard STC rating of 42, 45, 49, 50, and 51, offers a wide selection of sound control choices.
All folding partition walls panel components (top seals, bottom seals, expander closure mechanisms, etc.) are accessible from the panel perimeter and do not require removal of panel faces making panels the most serviceable panel on the market today.
Technical Details
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Passdoors | Single door or Double door |
| Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) |
