Customized Aluminum Frame Foldable Operable Acoustic Partition Walls
Acoustic Partition Wall Melamine Finish
The acoustic partition wall series is the most popular specification range of fully operational single-panel sliding partition systems. The noise reduction of up to 50dB noise is achieved with a combination of operable top and bottom seals, high performance multiple sound absorbing material in partition walls and panel assembly design which allows noise reduction between the frame and the outer layer.
The vertical channel of each acoustic partition wall panel contains a polymer insert that is acoustic sealed when the panels are placed as a wall. The sound insulation partition walls are available in three thicknesses, 65mm, 80mm and 100mm, depending on the acoustic rating (from 30dB to 50dB).
Specifications of Acoustic Movable Partition Walls System
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9mm | 9mm | 12 mm |
| Pass doors | Single door or Double door |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Advantages of Acoustic Partition Walls
Many panel stack options are completely flexible;
No floor track to get in the way;
Individual acoustic partition wall panel can be stored to maximize the use of space.
Operable top and bottom seals for easy operation;
A wide range of surface finishes are available for acoustic partition walls.
High performance multiple fill for maximum noise reduction;
Sound insulation aluminum frame structure, enhance the acoustic effect;
Unique track systems ensure quiet and easy operation;
Three panel thickness are available for a variety of acoustic requirements.
