Customized Soundproof Office Wooden Partition Wall , Movable Room Dividers

Name: Customized Soundproof Office Wooden Partition Wall Movable Room Dividers
Brand: BANGE
Price: 1 USD

China Customized Soundproof Office Wooden Partition Wall , Movable Room Dividers wholesale

Brand Name : BANGE

Model Number : 85 mm wooden partition walls

Certification : ISO9001

Place of Origin : Guangdong

MOQ : 10 square meters

Price : US Dollars 80 - 120 per square meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 square meters per month

Delivery Time : 15-20 days

Packaging Details : Carton package, MDF batten on four section sides , foam board on both front face.

Color : Accept customized

Application : Hotel,banquet hall

Panel width : 500 mm--1230 mm

Door material : Melamine board

Surface : Leather

Position : Interior

Open style : Sliding

Feature : Sound insulation

Product name : Wooden partition walls

Size : 85 mm(3 1/4 inch)

Contact Now

Customized Design Soundproof Office Movable Dividers Sliding Wooden Partition Wall

Product Details:

Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Specification
Model	Weight (kg/m)	Fire Rating(min)	STC Performance	Thickness (mm)	Width(mm)	Height(mm)	Top Seal(mm)/ Pressure(kg)	Bottom Seal(mm)/ Pressure(kg)	LCP stretch (mm)
BG65-32	22	60	32db	65	680-1212	2000-4500	22.5/35	22.5/35	140
BG65-38	27	60	38db	65	680-1212	2000-4500	22.5/35	22.5/35	140
BG65-45	35	60	45db	65	680-1212	2000-4500	22.5/35	22.5/35	140

1. Track: The material is made of 6063-T6 anodized aluminum, used for hanging screens.

2. Double-level hanging wheel: The roller is made of POM imported from South Korea. The material of the screw is No. 45 quenched and tempered steel. The hanging screen can be rotated at any angle in the horizontal plane. It can pass through the track L, T, X along the pulley. intersection.

3. Hanging wheel seat: material is A3 steel, connecting the role of double horizontal hanging wheel and screen.

4. On the pressure: the material is anodized aluminum, sealed screen and the ground, the gap between the ceiling, sound and double as a fixed role.

5. Sealant strip: PVC polyvinyl chloride material, the surface color is black, seal sound, seal light, contact
wall buffer effect.

6. Reference plate: Medium density fiberboard, all in line with GB/T11718-1999.

7. Sound insulation cotton: PAR sound-absorbing glass fiber, fire performance, thermal resistance and noise reduction coefficient are in line with the United States ASTM standards.

8. Border sealer: material for the anodized aluminum, vertical embedded lock, can seal from the screen border narrow gap leakage.

9. Telescopic mechanism: Material is standard 45 steel and spring steel, pressure spring type operation, can automatically adjust the gap between the screen and the ground.

10. Stirring bar: Material is standard 45 steel, used to operate up and down, left and right telescopic mechanism.

11. Cover: material is a standard 45 steel, black chrome plating, built-in spring protection rod device.

Customized Soundproof Office Wooden Partition Wall , Movable Room Dividers
Specifications:

1. Floorless suspension: There is no track on the floor, just install the track on the ceiling;

2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;

3. Soundproof and environmental protection: Sound insulation effect is good, the maximum sound insulation coefficient can reach 53dB;

4. Insulation and energy conservation: Excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;

5. High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance;

6. Beautiful and generous: Any surface decoration, can be combined with the indoor decoration effect;

7. Retractable and flexible: The partitions move freely, promote flexibility, and one person can complete the entire process of partitioning;

8. Convenient collection: When closing, the partition can be hidden in a dedicated storage cabinet, which does not affect the overall appearance;

9. Wide range of applications: Can be used in conference halls, exhibition halls, restaurants, high-cleaning factories and offices;
Customized Soundproof Office Wooden Partition Wall , Movable Room Dividers

Series	BG65	BG80 / BG85	BG100 & BG125
Panel suspension	Top hung only	Top hung only	Top hung only
Track system	Single or twin point	Single or twin point	Single or twin point
Panel thickness	65mm	80mm / 85mm	100mm
Panel height	Up to 4000mm	Up to 6000mm	Up to 18000mm
Max height	4000mm	6000mm	18000mm
Panel width	600-1230mm	600-1230mm	600-1230mm
Frame construction	Aluminum frame	Aluminum frame	Aluminum frame
Face material	9mm	9mm / 12mm	12mm
Fire safety	Optional Class I or O	Optional Class I or O	Optional Class I or O
Vertical profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles
Retractable seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals
Operation of seals	Manual, with supplied operating handle	Manual, with supplied operating handle	Manual, with supplied operating handle
Locking	Optional lock to pass doors	Optional lock to pass doors	Optional lock to pass doors
Pass doors	Single open in panel or double open in two panel	Single open in panel or double open in two panel	Single open in panel or double open in two panel
Sound insulation	20-32dB Rw	28-36dB Rw	32-50dB Rw
Weight	Approx 22-35kg/sq M	Approx 25-40kg/sq M	Approx30-48kg/sq M
Finish Material	Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized)

Common Applications:

BUNGE soundproof movable partition wall can be used to Convention Centers, Gymnasiums, Religious Facilities, Hotels, Auditoriums, Corporate Training Facilities, Civic or Exposition Halls, Schools, Banquet Facilities, etc.

With movable partition wall systems, there are no more barriers to maximizing the potential of your available building spaces.
